SIEMENS 6ES7131-4BB00-0AA0 ET200S, EL-MOD., 2DI ST, 24V DC, 5PCS. 5 ELECTRON. MODULES FOR ET 200S, 2 DI STANDARD 24V DC
Here are the key details on the Siemens 6ES7131-4BB00-0AA0 ET200S, 2DI ST, 24V DC Electronic Modules:
Product Details:
- Model Number: 6ES7131-4BB00-0AA0
- Product Name: ET200S, 2DI ST, 24V DC Electronic Modules
Description:
The Siemens 6ES7131-4BB00-0AA0 is a set of 5 electronic modules for the SIMATIC ET200S distributed I/O system. Each module provides 2 digital input channels with a nominal input voltage of 24V DC.
Key Features:
- 5 electronic modules in the package
- 2 digital input channels per module
- Nominal input voltage: 24V DC
- Electronic modules for ET200S
- Supports SIMATIC ET200S distributed I/O system
- Compact, space-saving design
- Screw terminals for connections
- Integrated diagnostics and status LEDs
Detailed Specifications:
- Number of Digital Inputs per Module: 2
- Input Voltage: 24V DC
- Input Delay Time: 0.1 ms
- Dimensions (W x H x D) per Module: 15 x 81 x 52 mm
- Mounting: DIN rail
- Connections: Screw terminals
- Operating Temperature: 0°C to +60°C
- Approvals: CE, UL, cUL
The Siemens 6ES7131-4BB00-0AA0 ET200S, 2DI ST, 24V DC Electronic Modules are compact and versatile digital input modules designed for use in the SIMATIC ET200S distributed I/O system. Each module provides 2 digital input channels with a nominal input voltage of 24V DC.
These digital input modules are suitable for a wide range of industrial automation and control applications, such as:
- Process automation
- Factory automation
- Building automation
- Machine control
- Conveyor systems
- Other industrial applications requiring a high-density 24V DC digital input interface
The compact design and DIN rail mounting allow the digital input modules to be easily integrated into the SIMATIC ET200S distributed I/O system, providing a flexible and scalable solution for industrial control and monitoring applications.
Please note that proper selection, installation, and configuration of the digital input modules is important to ensure their optimal performance and compatibility with the specific automation system and application requirements. It is recommended to consult with Siemens or a qualified automation engineer for guidance on the selection and use of these SIMATIC ET200S electronic modules.
| Product |
| Article Number | 6ES7131-4BB00-0AA0 |
| Product Description | SIMATIC DP, 5 ELECTRON. MODULES FOR ET 200S, 2 DI STANDARD 24V DC, 15 MM WIDTH, 5 PIECES PER PACKAGING UNIT |
| Product family | Not available |
| Product Lifecycle (PLM) | PM500:Discontinued Product or end of PLM & Support |
| PLM Effective Date | End of product lifecycle since: 01.10.2012 |
| Notes | |
| Successor information |
| Successor | 6ES7131-4BB01-0AA0 |
| Successor Description | *** Spare part *** SIMATIC DP, 5 electronic modules for ET 200S, 2 DI Standard 24 V DC, 15 mm width, 5 units per packing unit |
| Price data |
| Price Group | 2AP |
| List Price | Show prices |
| Customer Price | Show prices |
| Surcharge for Raw Material | see also metal factor (further details are available on the help page) |
| Metal Factor | see also metal factor (further details are available on the help page) |
| Delivery information |
| Export Control Regulations | ECCN : EAR99H / AL : N |
| Estimated dispatch time (Working Days) | 1 Day(s) |
| Net Weight (kg) | 0,176 Kg |
| Packaging Dimension | 9,10 x 8,40 x 6,20 |
| Package size unit of measure | CM |
| Quantity Unit | 0 Package |
| Packaging Quantity | 5 |
| Additional Product Information |
| EAN | 4025515058038 |
| UPC | Not available |
| Commodity Code | 85389091 |
| LKZ_FDB/ CatalogID | ST9-E5 |
| Product Group | 2301 |
| Group Code | R111 |
| Country of origin | Germany |
|
|
